Shenzhen Chinasky Laser Technology Co., Ltd. is one of the most professional manufacturers and suppliers of aluminum body handheld laser marking machine in China. Please rest assured to buy high quality aluminum body handheld laser marking machine with 2 years warranty from our factory. We also accept customized orders.
Product Introduction
The Aluminum Body Handheld Laser Marking Machine is a portable laser marker suitable for marking text, patterns, and QR codes on materials such as metal, plastic, and wood.
Product Features
Durable: The Aluminum Body Handheld Laser Marking Machine features a high-strength aluminum alloy body and precision laser optics, capable of withstanding long-term vibration and impact, with a service life of ≥5 years.
Lightweight and Portable: Weighing approximately 6kg, the machine is easy to operate by hand and can be moved freely in factories, workshops, or on-site.
Highly Efficient: Marking speeds up to 7000mm/s allow for rapid batch marking of workpieces.
Customizable: Power, marking range, and appearance design can be customized according to drawings or samples.
FAQ
Q: Do you provide sample testing?
A: Yes. Customers can provide samples for free or for a fee to confirm the processing effect and equipment selection.
Q: What is the typical delivery time?
A: Standard equipment is usually delivered in 1–6 weeks, depending on the configuration and order quantity.
Q: How does it work?
A: The Aluminum Body Handheld Laser Marking Machine creates permanent marks by ablating the material surface with a laser, achieving precise marking without contact.
Q: Is installation complicated?
A: No. The handheld design requires no fixing; simply hold it or use a stand.
Q: Is the marking depth adjustable?
A: Yes. Shallow or deep markings can be achieved by adjusting the power to meet different needs.
Q: Is it safe?
A: Yes. Equipped with a laser safety shield to reduce operational risks and minimize dust contact.
Q: Is maintenance complicated?
A: No. Routine cleaning of the optical lenses is sufficient; maintenance is simple and convenient.
Hot Tags: aluminum body handheld laser marking machine, China aluminum body handheld laser marking machine manufacturers, suppliers, factory, CO2 Flying Laser Marking Machine, Desktop Fiber Laser Marking Machine, Fully Close Fiber Laser Marking Machine, Jewellery Hallmarking Machine, Online Flying Laser Marking Machine, Visual Position Laser Marking Machine
Technical Parameters
|
Model |
HT-FH20 |
HT-FH30 |
HT-FH50 |
|
Laser power |
20w |
30w |
50W |
|
Marking range |
75x75mm |
||
|
Laser Wavelength |
1064mm |
||
|
Output Frequency of Laser |
27-60Hz |
||
|
Marking Speed |
≤10000mm/s |
||
|
Operation System |
Linux |
||
|
Minimum line width |
0.1mm |
||
|
Minimum character |
0.15mm |
||
|
Repeating precision |
0.005mm |
||
|
Cooling system |
Air cooling |
||
|
Positioning method |
Red light positioning |
||
|
Power supply |
500W / 100-240V / 50/60Hz |
||
|
Laser cabint dimensions |
255x135x200 mm |
275x150x200 mm |
|
|
Machine net weight |
6 kg (laser head 1.25kg) |
6.5 kg (laser head 1.25kg) |
|
